Features
We exclusively research and develop the extruder feeding system and guide rail, which support high-speed printing. Its printing accuracy can reach high to 0.04mm,and it allows to extrude filament steady without block.
The whole-steel body not only ensure the stability when printing, but also extend the usage period greatly. Its optimization and cooperation of overall structure ensure the sustainable and efficient operation. The first batch of CreatBot 3D printers have been working for 9 years and more than 30,000 hours.
The fully enclosed chamber blocks all external interfernce and reduces the noise generated by the machine. The Hot chamber device provides a constant room temperature of 70°C, which prevents the prints from warping and deforming.
The printer will memorize the current position and save that information in its database. In an event of an outage, the platform will automatically be lowered and the filament withdrawn.Upon power restoration, the printer will continue to print from the last stopped point prior to the outage The printer will avoid any invalid prints by stopping the print. A warning will be indicated when the filament runs out.
The printer has an all-english-menu touch screen which is easy and user friendly. Shortkeys such as warming and print minimizes the number of buttons to press at one point in time.
Material is made of a combination of Glass-Ceramic Platform and Carbon Fiber Sheet.
The Glass-Ceramic has high thermal efficiency and the optimal low-expansion coefficient preventing your model from deforming while heating and cooling.
The carbon fiber sheet is tough and detachable allowing heat to be delivered efficiently. Most materials can be extruded and sticks to bed very well.
The air filter system can adsorb impurities and gases generated by the filament. This allows for a safer and environmentally friendly work space. This makes the printer ideal for house, school and office usage.
BLtouch is a smart device which makes use of 25 points to probe and store the level of platform data. It automatically calculates against the Z axis intelligent compensation table height achieving fully automatic levelling.
Technical specs
| Printing | |
| Print Technology | Fused Deposition Modeling（FDM） |
| Build Volume | 400*300*300 mm |
| Number of Nozzles | Double |
| Accuracy | 0.04 mm |
| Layer Resolution | 0.02 mm |
| Filament Diameter | 1.75 mm |
| Filament Compatibility | PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PETG, HIPS, PP, Flexible, TPU, PVA, PEEK, etc. |
| Nozzle Diameter | 0.4mm (0.3 0.5 0.6 0.8 1.0mm) |
| Print File Type | STL, OBJ, AMF, Gcode |
| Speed | |
| Best Printing speed | 55 mm/s |
| Max. Printing speed | 180 mm/s |
| Electrical | |
| Power Requirements | 100V-110V or 200V-240V / 50-60Hz (Depending on your country’s default voltage) |
| Max. Power | 1500W |
| Screen | 4.3” Touch Screen |
| Control Chip | ATmega 2560 |
| Storage Media | U Disk |
| Connectivity | USB |
| Special Function | |
| Outage Restored | Save data when power is off |
| Filament Detection | Pause printing when filament run out |
| Automatic Shut-down | Turn off the power automatically when printing is complete |
| Temperature | |
| Ambient Operating Temperature | 15 ℃~32 ℃ |
| Max. Nozzle Temperature | 420 ℃ |
| Max. Bed Temperature | 140 ℃ |
| Max. Chamber Temperature | 70 ℃ |
| Mechanical | |
| Construction | Power-Coated Steel, Aluminum Casting for Motion Components |
| Build Plate | Glass Ceramic Panel |
| Build Plate Leveling | Automatic |
| Extruder | Directly Drive |
| Stepper Motors | 1.8° Step Angle with 1/16 Micro-stepping |
| X Y Positioning Precision | 12.7 μm |
| Z Positioning Precision | 1.25 μm |
| Software | |
| Software Bundle | CreatWare, Simplify 3D, Cura, Slice 3r, etc |
| Supported File Types | STL,OBJ,AMF |
| Operating Systems | Win7/8/10, MacOS |
| Size & Weight | |
| Product Dimensions & Weight | 620*485*680 mm 48 kg |
| Packing Size & Weight | 750*580*720 mm 62 kg |
| |||||||||||||||||||||||||||||||||||||||||
